CBA EXTERNAL FINISH BORING HEAD
High-performance CBA Micro-adjustment External Finish Boring Head with aerospace-grade aluminum construction. Engineered for precision external finish boring, featuring micro-adjustment capability and versatile size range from 10mm to 90mm.
| Specifications | Details |
|---|---|
| Material | Aerospace-grade Aluminum |
| External Diameter Range | 10mm~90mm |
| Boring Range | Φ116~Φ200mm |
| Boring Adapter | FMB22 / BST |
| Insert Type | TP*08020*L / TC*11020*L |
| Special Feature | Reverse installation for back boring |
Product Details
specifications
| Product Model Micro-adjustment External Finish Boring Head |
External Circle Range ΦD | L1 | L | Boring Adapter | Insert | Weight(kg) |
|---|---|---|---|---|---|---|
| CBA10-20 | 10-20mm | 40mm | 78mm | FMB22 | TP*08020*L | 0.8 |
| CBA20-30 | 20-30mm | 40mm | 78mm | 0.9 | ||
| CBA30-40 | 30-40mm | 40mm | 78mm | 0.85 | ||
| CBA40-50 | 40-50mm | 40mm | 78mm | 1.0 | ||
| CBA150 | 30-90mm | 60mm | 124mm | BST | TC*11020*L | 3.3 |
Get customized solutions now
PRODUCT PREVIEW
CBA Micro-adjustment External Finish Boring Head
The CBA Micro-adjustment External Finish Boring Head is a precision-engineered solution for CNC machining operations requiring high accuracy in external finish boring applications. Designed with advanced micro-adjustment technology and aerospace-grade aluminum construction, this boring head provides exceptional rigidity, stability, and operational simplicity for producing precise external diameters with superior surface finish quality.
Technical Key Features
- Aerospace-Grade Aluminum Construction: Utilizes high-quality aerospace aluminum material for enhanced efficiency, stability, and operational simplicity.
- Versatile Size Range: Available in multiple configurations covering external diameters from 10mm to 90mm, accommodating various machining requirements.
- Micro Adjustment Capability: Features precise micro-adjustment for fine-tuning external diameter control.
- Modular Insert System: Designed with separate insert holders, allowing for flexible insert selection and replacement.
- Reverse Installation Capability: Can be installed in reverse for back boring applications, expanding its versatility.
- Wide Boring Range: Covers external boring ranges from Φ116mm to Φ200mm for comprehensive machining capabilities.
Application Range
This series excels in processing a wide range of external finish boring applications:
- External Finish Boring: Ideal for high-precision external diameter machining with excellent surface finish
- Versatile Size Applications: Suitable for components with external diameters from 10mm to 90mm
- Precision Manufacturing: Essential for industries requiring tight tolerances and superior surface finishes
- Back Boring Capability: Reverse installation enables back boring for complex machining operations
Why Choose CBA for Your CNC Operations?
In modern manufacturing environments, precision, efficiency, and versatility are critical. The CBA micro-adjustment external finish boring head features advanced aerospace-grade aluminum construction combined with micro-adjustment technology for superior external boring performance. Its modular design and reverse installation capability make it an essential tool for achieving tight tolerances, excellent surface finishes, and expanded machining capabilities in precision manufacturing applications.
